We can and have built the entire machine, except for the gear box and motor.
Generally, we can re-produce a replacement part by reverse-designing a part from a drawing, or with a photograph, and the following information:
Click on part above to access a blank drawing PDF to fill out or print.
We have a proprietary choke that is less expensive and simpler than the O.E.M.
We are more than pleased to produce custom parts for your machine.
We will make your parts from what ever alloy you desire.
Part Number Cross reference:
14 in Machine Parts
| Part Description | Machine Size | O.E.M. | Geronimo Part Number |
| CUTTER | 14″ | E-851 | |
| FEED WORM | 14″ | RP35847 | F0920 |
| NOT. WORM | 14″ | RP34550 | F0921 |
| SOL. BRG. WORM | 14″ | RP34549 | F0922 |
| SOLID WORM | 14″ | RP34786 | F0923 |
| SOL. WORM | 14″ | MP13285 | F0945A |
| SOL. WORM | 14″ | MP11967 | F0961A |
| SPLIT BUSHING | 14″ | RP31269 | F1013 |
| BREAKER BAR | 14″ | B-51-63245-01 | F1014 |
| BREAKER BAR | 14″ | B-51-63246-01 | F1015 |
| T-COLLAR | 14″ | RP23502 | F1058 |
| COLLAR | 14″ | RP27370 | F1060 |
| COLLAR | 14″ | RP28876 | F1062 |
| COLLAR | 14″ | RP23505 | F1063 |
| NOT. WORM | 14″ | MP11966 | F1090A |
| DISCH. END | 14″ | MP13337 | F1091 |
| SOL. WORM | 14″ | MP13283 | F1092A |
| SOL. WORM | 14″ | MP13391 | F1093A |
| T-COLLAR | 14″ | F1094 | |
| PRESSURE COLLAR | 14″ | F1095 | |
| SPACER BUTTONS | 14″ | F1104 | |
| SCREEN BAR | 14″ | F1105 | |
| KEYBAR | 14″ | F1106 | |
| BREAKER BAR | 14″ | B-51-53943-01 | F1113 |
| BREAKER BAR | 14″ | B-51-53944-01 | F1114 |
| BREAKER BAR | 14″ | B-51-53939-01 | F1122 |
| COLLAR | 14″ | MP12372 | F1125 |
| BREAKER BAR | 14″ | B-51-53940-01 | F1132 |
| FEED WORM | 14″ | MP11962 | F1153 |
| SOL. WORM | 14″ | C-51-54077-01 | F1154 |
| NOT. WORM | 14″ | MP13427 SK-1691 | F1155A |
| BREAKER BAR | 14″ | MP13292 | F1170 |
| SOL. WORM | 14″ | MP13284 | F1180A |
| 2 SECTION CAGE LH | 14″ | RP25991 | F1181 |
| 2 SECTION CAGE RH | 14″ | RP25992 | F1182 |
| ORIFICE | 14″ | C-51-54076-01 | F1185 |
| SCREEN BARS | 14″ | F1199 | |
| KEYBAR | 14″ | F1200 | |
| SHAFT BUSHING | 14″ | RP31269 | F1207 |
| SOLID INSERT CAGE | 14″ | F1217 | |
| END WORM | 14″ | C-51-54079-01 | F1250 |
| 4 SECTION CAGE RH | 14″ | F1273 | |
| 4 SECTION CAGE LH | 14″ | F1274 | |
| SOLID CAGE SLEEVE | 14″ | F1275 | |
| BREAKER BAR | 14″ | B-51-53941-01 | F1276 |
| END CAP | 14″ | RP33549 | F1285 |
| END OVER | 14″ | F1286 | |
| BREAKER BAR | 14″ | MP13290 | F1289 |
| COLLAR | 14″ | MP11030 | F1292 |
| T-COLLAR | 14″ | MP11431 | F1293 |
| T-COLLAR | 14″ | MP11432 | F1294 |
| WATER COOLING SLEEVE | 14″ | MP17467 | F1321 |
| SOLID INSERT CAGE | 14″ | F1328 | |
| COLLAR | 14″ | F1334 | |
| T-COLLAR | 14″ | MP13393 | F1343 |
| BREAKER BAR | 14″ | B-51-53942-01 | F1344 |
| FEEDWORM | 14″ | RP35847 | F1346 |
| TAP. WORM | 14″ | C-51-54074-01 | F1376 |
| SOL. WORM | 14″ | C-51-54075-01 | F1377 |
| NOT. WORM | 14″ | RP35069 | F1379A |
| SOL. WORM | 14″ | RP34786 | F1380 |
| SOL. WORM | 14″ | C-51-54073-01 | F1381 |
| SOL. WORM | 14″ | RP34554 | F1389 |
| BREAKER BAR | 14″ | B-51-70430-01 | F1422 |
| BREAKER BAR | 14″ | MP13289 | F1447 |
| 2 SECTION CAGE LH | 14″ | MP27420 | F1516 |
| 2 SECTION CAGE RH | 14″ | MP21535 | F1517 |
| 4 SECTION CAGE RH | 14″ | F1518 | |
| 4 SECTION CAGE LH | 14″ | F1519 | |
| CENTER BAR | 14″ | MP11955 | F1523 |
| T-COLLAR | 14″ | D-51-50605-47 | F1560 |
| T-COLLAR | 14″ | D-51-50605-48 | F1561 |
| COLLAR | 14″ | RP23508 | F1562 |
| T-COLLAR | 14″ | D-51-50605-46 | F1563 |
| COLLAR | 14″ | D-51-51300-76 | F1564 |
| T-COLLAR | 14″ | D-51-50605-26 | F1565 |
| COLLAR | 14″ | D-51-51300-75 | F1566 |
| COLLAR | 14″ | D-51-51300-07 | F1567 |
| COLLAR | 14″ | D-51-51300-74 | F1568 |
| T-COLLAR | 14″ | D-51-50605-45 | F1569 |
| COLLAR | 14″ | D-51-51300-39 | F1570 |
| COLLAR | 14″ | D-51-51300-04 | F1571 |
| COLLAR | 14″ | RP23506 | F1572 |
| COLLAR | 14″ | D-51-51300-73 | F1573 |
| COLLAR | 14″ | RP23508 | F1574 |
| COLLAR | 14″ | D-51-51300-72 | F1575 |
| COLLAR | 14″ | D-51-51300-71 | F1576 |
| SOLID WORM | 14″ | RP34351 | F1577 |
| NOT. WORM | 14″ | C-51-65163-01 | F1578 |
| SOL. BRG. WORM | 14″ | MP34579 | F1579 |
| NOT. WORM | 14″ | MP17273 | F1580 |
| DISCHARGE END | 14″ | MP19833 | F1581 |
| SPLIT BUSHING | 14″ | F1598 | |
| SPLIT BUSHING | 14″ | RP31269 | F1649 |
| NOTCHED SCREEN BAR | 14″ | RP32584 | F2092 |
| NOTCHED SCREEN BAR | 14″ | RP32585 | F2093 |
| KEY BAR | 14″ | F2094 | |
| KEYBAR | 14″ | F2095 | |
| SPACER | 14″ | F2097 | |
| FEED WORM | 14″ | F2098 | |
| T-COLLAR | 14″ | F2099 | |
| SOL. WORM | 14″ | F2100 | |
| T-COLLAR | 14″ | RP32571 | F2101 |
| NOT. WORM | 14″ | MP18923 | F2102 |
| NOT. WORM | 14″ | MP18915 | F2102 |
| COLLAR | 14″ | RP32722 | F2103 |
| SOL. BRG. WORM | 14″ | MP18919 | F2104 |
| T-COLLAR | 14″ | MP14145 | F2105 |
| SOL. WORM | 14″ | RP33076 | F2106 |
| COLLAR | 14″ | F2107 | |
| NOT. WORM | 14″ | MP19624 | F2108 |
| SOL. BRG. WORM | 14″ | MP19625 | F2109 |
| T-COLLAR | 14″ | RP32572 | F2110 |
| T-COLLAR | 14″ | RP32573 | F2111 |
| T-COLLAR | 14″ | MP19739 | F2112 |
| SOL. WORM | 14″ | MP18915 | F2113 |
| DISCH END | 14″ | RP32570 | F2114 |
| BREAKER BAR | 14″ | MP20803 | F2115 |
| BREAKER BAR | 14″ | RP32586 | F2116 |
| BREAKER BAR | 14″ | RP32587 | F2117 |
| BREAKER BAR | 14″ | RP32588 | F2118 |
| BREAKER BAR | 14″ | RP33168 | F2119 |
| BREAKER BAR | 14″ | RP32590 | F2120 |
| BREAKER BAR | 14″ | RP32591 | F2121 |
| BREAKER BAR | 14″ | RP32592 | F2122 |
| NOTCHED SCREEN BAR RETAINING RING | 14″ | RP32785 | F2147 |
| CAGE DOWEL | 14″ | F2155 | |
| COLLAR | 14″ | F2173 | |
| BREAKER BAR | 14″ | MP13289 | F2180 |
| BREAKER BAR | 14″ | F2181 | |
| BREAKER BAR | 14″ | MP13291 | F2182 |
| BREAKER BAR | 14″ | F2183 | |
| SHAFT | 14″ | F2286 | |
| SPACER | 14″ | F2352 | |
| SPACER | 14″ | F2353 | |
| DISCH. END | 14″ | F2354 | |
| 4 SECTION CAGE RH | 14″ | F2363 | |
| SPACER | 14″ | D-51-55153-03 | F2398 |
| FEED WORM | 14″ | MP23515 | F2399 |
| COLLAR | 14″ | D-51-51300-31 | F2400 |
| WORM | 14″ | MP36275 | F2401 |
| T-COLLAR | 14″ | MP35749 | F2402 |
| WORM | 14″ | MP34527 | F2403 |
| COLLAR | 14″ | D-51-51300-33 | F2404 |
| WORM | 14″ | MP34785 | F2405 |
| T-COLLAR | 14″ | D-51-50605-18 | F2406 |
| WORM | 14″ | MP34786 | F2407 |
| COLLAR | 14″ | D-51-51300-08 | F2408 |
| N-WORM | 14″ | MP17273 | F2409 |
| T-COLLAR | 14″ | MP33165 | F2411 |
| COLLAR | 14″ | MP23508 | F2413 |
| WORM | 14″ | MP34351 | F2414 |
| DISCH. END | 14″ | D-51-76151-01 | F2415 |
| BREAKER BAR | 14″ | F2430 | |
| BREAKER BAR | 14″ | F2431 | |
| BREAKER BAR | 14″ | F2432 | |
| BREAKER BAR | 14″ | F2433 | |
| BREAKER BAR | 14″ | F2434 | |
| BREAKER BAR | 14″ | F2441 | |
| BREAKER BAR | 14″ | F2442 | |
| BREAKER BAR | 14″ | F2443 | |
| BREAKER BAR | 14″ | F2444 | |
| BREAKER BAR | 14″ | F2445 | |
| BREAKER BAR | 14″ | F2446 | |
| BREAKER BAR | 14″ | F2447 | |
| BREAKER BAR | 14″ | F2448 | |
| BREAKER BAR | 14″ | F2449 | |
| BREAKER BAR | 14″ | F2450 | |
| SPACER | 14″ | F2451 | |
| FEED WORM | 14″ | F2452 | |
| T-COLLAR | 14″ | F2453 | |
| T-COLLAR | 14″ | F2454 | |
| COLLAR | 14″ | F2455 | |
| NOT. WORM | 14″ | F2456 | |
| COLLAR | 14″ | F2457 | |
| COLLAR | 14″ | F2458 | |
| COLLAR | 14″ | F2459 | |
| SOL. WORM | 14″ | F2460 | |
| T-COLLAR | 14″ | F2461 | |
| SHAFT | 14″ | F2462 | |
| SOL. WORM | 14″ | RP34553 | F2473 |
| COLLAR | 14″ | D-51-51300-20 | F2474 |
| T-COLLAR | 14″ | F2475 | |
| SOL. WORM | 14″ | RP34531 | F2476 |
| T-COLLAR | 14″ | F2477 | |
| SPACER | 14″ | F2478 | |
| FEED WORM | 14″ | F2479 | |
| COLLAR | 14″ | F2480 | |
| SOL. WORM | 14″ | F2481 | |
| SOL. WORM | 14″ | F2482 | |
| T-COLLAR | 14″ | F2483 | |
| SOL. WORM | 14″ | F2484 | |
| T-COLLAR | 14″ | F2485 | |
| NOT. WORM | 14″ | F2486 | |
| COLLAR | 14″ | F2487 | |
| T-COLLAR | 14″ | F2488 | |
| NOT. WORM | 14″ | F2489 | |
| DISCH. END | 14″ | F2490 | |
| BREAKER BAR | 14″ | F2491 | |
| BREAKER BAR | 14″ | F2492 | |
| BREAKER BAR | 14″ | F2493 | |
| BREAKER BAR | 14″ | F2494 | |
| SPACER | 14″ | F2495 | |
| BREAKER BAR | 14″ | F2501 | |
| BREAKER BAR | 14″ | F2502 | |
| BREAKER BAR | 14″ | F2503 | |
| BREAKER BAR | 14″ | F2504 | |
| BREAKER BAR | 14″ | F2505 | |
| BREAKER BAR | 14″ | F2506 | |
| BREAKER BAR | 14″ | F2507 | |
| BREAKER BAR | 14″ | F2508 | |
| CENTER BAR | 14″ | F2509 | |
| SPACER | 14″ | F2510 | |
| SPACER | 14″ | F2511 | |
| T-COLLAR | 14″ | F2512 | |
| T-COLLAR | 14″ | F2513 | |
| COLLAR | 14″ | F2514 | |
| T-COLLAR | 14″ | F2515 | |
| T-COLLAR | 14″ | F2530 | |
| COLLAR | 14″ | F2531 | |
| SOL. BRG. WORM | 14″ | F2532 | |
| SOL. WORM | 14″ | F2545 | |
| COLLAR | 14″ | F2701 | |
| DISCH. END | 14″ | F2702 | |
| BREAKER BAR | 14″ | F2703 | |
| BREAKER BAR | 14″ | F2704 | |
| BREAKER BAR | 14″ | F2705 | |
| BREAKER BAR | 14″ | F2706 | |
| NOT. WORM | 14″ | F2708 | |
| COLLAR | 14″ | F2709 | |
| T-COLLAR | 14″ | F2710 | |
| SHAFT | 14″ | F2803 | |
| DISCHARGE END | 14″ | F2805 | |
| SPLIT DIE PLATE | 14″ | F2806 | |
| 4 SECTION CAGE LH | 14″ | F2840 | |
| 4 SECTION CAGE RH | 14″ | F2841 | |
| BREAKER BAR | 14″ | B-51-64996-01 | F3014 |
| BREAKER BAR | 14″ | B-51-64997-01 | F3015 |
| BREAKER BAR | 14″ | B-51-64998-01 | F3016 |
| BREAKER BAR | 14″ | B-51-64999-01 | F3017 |
| BREAKER BAR | 14″ | B-51-65000-01 | F3018 |
| BREAKER BAR | 14″ | B-51-65001-01 | F3019 |
| BREAKER BAR | 14″ | B-51-65002-01 | F3020 |
| BREAKER BAR | 14″ | B-51-65003-01 | F3021 |
| BREAKER BAR | 14″ | B-51-65004-01 | F3022 |
| BREAKER BAR | 14″ | B-51-65005-01 | F3023 |
| COLLAR | 14″ | F3193 | |
| BREAKER BAR | 14″ | F3194 | |
| BREAKER BAR | 14″ | F3195 |
10 1/4 in Machine Parts
| Part Description | Machine Size | O.E.M. | Geronimo Part Number |
| NOT. WORM | 10 1/4″ | C-51-59672-01 | F0719N |
| WORM | 10 1/4″ | C-51-59672-01 | F0719S |
| WORM | 10 1/4″ | C-51-59671-01 | F0806 |
| NOT. WORM | 10 1/4″ | C-51-59677-03 | F0808N |
| WORM | 10 1/4″ | C-51-59677-03 | F0808S |
| SCREEN BAR | 10 1/4″ | B-51-59425-01 | F0828 |
| KEY BAR | 10 1/4″ | B-51-59424-01 | F0829 |
| SCREEN BAR | 10 1/4″ | B-51-59416-01 | F0830 |
| KEY BAR | 10 1/4″ | B-51-59417-01 | F0831 |
| WORM | 10 1/4″ | C-51-59673-01 | F0833 |
| WORM | 10 1/4″ | C-51-59313-01 | F0839 |
| COLLAR | 10 1/4″ | D-51-51300-54 | F0861 |
| COLLAR | 10 1/4″ | D-51-51300-53 | F0864 |
| BREAKER BAR | 10 1/4″ | B-51-59557-01 | F0952 |
| BREAKER BAR | 10 1/4″ | B-51-59558-01 | F0953 |
| BREAKER BAR | 10 1/4″ | B-51-59561-01 | F0962 |
| BREAKER BAR | 10 1/4″ | B-51-59562-01 | F0965 |
| THERMOCOUPLE BAR | 10 1/4″ | B-51-59653-01 | F1428 |
| WORM | 10 1/4″ | C-51-59320-01 | F1448 |
| SPACER | 10 1/4″ | RP31957 | F1691 |
| CENTER BAR | 10 1/4″ | RP27201 | F1754 |
| FEEDWORM | 10 1/4″ | C-51-59670-01 | T0001 |
| T-COLLAR | 10 1/4″ | D-51-50605-29 | T0002 |
| WORM | 10 1/4″ | C-51-59495-01 | T0007 |
| T-COLLAR | 10 1/4″ | B-51-59325-01 | T0008 |
| NOT. WORM | 10 1/4″ | C-51-59671-01 | T0009N |
| T-COLLAR | 10 1/4″ | D-51-50605-31 | T0010 |
| WORM | 10 1/4″ | C-51-59319-01 | T0011 |
| ORIFICE | 10 1/4″ | C-51-59333-02 | T0012 |
| COLLAR | 10 1/4″ | B-51-59323-02 | T0013 |
| WORM | 10 1/4″ | C-51-59311-03 | T0014 |
| T-COLLAR | 10 1/4″ | D-51-57605-32 | T0015 |
| T-COLLAR | 10 1/4″ | D-51-50605-30 | T0016 |
| T-COLLAR | 10 1/4″ | D-51-50605-33 | T0017 |
| WORM | 10 1/4″ | C-51-59316-02 | T0018S |
| COLLAR | 10 1/4″ | D-51-51300-55 | T0019 |
| BREAKER BAR | 10 1/4″ | B-51-59559-01 | T0020 |
| BREAKER BAR | 10 1/4″ | B-51-59560-01 | T0021 |
| T-COLLAR | 10 1/4″ | B-51-53527-01 | T0096 |
| WATER COOLING SLEEVE | 10 1/4″ | MP12064 |
7 in Machine Parts
| Part Description | Machine Size | O.E.M. | Geronimo Part Number |
| SCREEN BAR | 7″ | B-51-52837-01 | F0704 |
| SCREEN BAR | 7″ | B-51-63588-01 | F0707 |
| SPLIT BUSHING | 7″ | B-51-63589-01 | F0716 |
| SOL. BRG. WORM | 7″ | RP33938 | F0718 |
| SOL. BRG. WORM | 7″ | RP36203 81 | F0800 |
| FEEDWORM | 7″ | C-51-63564-01 | F0835 |
| SOL. WORM | 7″ | RP33928 | F0836 |
| SOL. WORM | 7″ | RP33932 | F0837 |
| SOL. BRG. WORM | 7″ | RP36203 | F0838 |
| SOL. BRG. WORM | 7″ | RP36204 | F0859 |
| SPACER BUTTONS | 7″ | B-51-52840-06 | F0985 |
| CENTER BAR | 7″ | B-51-64085-01 | F1128 |
| SOL. BRG. WORM | 7″ | F1267 | |
| SPECIAL COLLAR | 7″ | B-51-64384-01 | F1308 |
| SOL. WORM | 7″ | C-51-63575-01 | F1637 |
| BREAKER BAR | 7″ | B-51-63425-01 | F1849 |
| BREAKER BAR | 7″ | B-51-63426-01 | F1850 |
| BREAKER BAR | 7″ | B-51-63427-01 | F1851 |
| BREAKER BAR | 7″ | B-51-63427-01 | F1852 |
| BREAKER BAR | 7″ | B-51-63429-01 | F1853 |
| BREAKER BAR | 7″ | B-51-63430-01 | F1854 |
| BREAKER BAR | 7″ | B-51-64085-01 | F1855 |
| SOL. WORM | 7″ | C-51-63565-01 | T0006 |
| TAP. COLLAR | 7″ | C-51-63572-01 | T0022 |
| TAP. COLLAR | 7″ | C-51-63572-01 | T0022 |
| TAP. COLLAR | 7″ | C-51-63572-02 | T0023 |
| TAP. COLLAR | 7″ | C-51-63572-02 | T0023 |
| SOL. WORM | 7″ | RP33930 | T0024 |
| TAP. COLLAR | 7″ | C-51-63572-03 | T0025 |
| TAP. COLLAR | 7″ | C-51-63572-04 | T0026 |
| SOL. WORM | 7″ | RP33936 | T0027 |
| TAP. COLLAR | 7″ | C-51-63571-01 | T0028 |
| COLLAR | 7″ | C-51-36571-03 | T0029 |
| NOTCH WORM | 7″ | RP33937 | T0030 |
| TAP. COLLAR | 7″ | C-51-63572-06 | T0032 |
| SOL. WORM | 7″ | RP36201 | T0033 |
| TAP. COLLAR | 7″ | C-51-63572-07 | T0034 |
| SOL. WORM | 7″ | RP36202 | T0035 |
| COLLAR | 7″ | C-51-63572-08 | T0036 |
| COLLAR | 7″ | C-51-63571-02 | T0037 |
| COLLAR | 7″ | C-51-63572-09 | T0038 |
| ORIFICE | 7″ | C-51-63576-01 | T0095 |
